3F Dìagon Soft UGR Tunable White
Code 23816
L<3000 cd/m² 65°
Average luminance <3000 cd/m² for angles >65°.
Installation Interdistance Transv.D = 1.20 x hu ‑ Long.D = 1.20 x hu.
Rhomboidal lenses with differentiated surfaces, etched and prismatic to optimise the orientation of the luminous flux, in opal methacrylate (PMMA).
3F Dìagon 596x596 ‑ DALI DT8 electronic wiring 230V‑50/60Hz
Code
Item
W
lm
K
CRI
L x A x H
IP
23816
3F Diagon 25W DT8 TW SOFT UGR 596x596
30
29
28
3567
2700
4000
6500
>80
596x596x30
43
3F Dìagon 621x621 ‑ DALI DT8 electronic wiring 230V‑50/60Hz
Code
Item
W
lm
K
CRI
L x A x H
IP
23823
3F Diagon 25W DT8 TW SOFT UGR 621x621
30
29
28
3567
2700
4000
6500
>80
621x621x30
43
ILLUMINOTECHNICAL
Direct symmetric distribution.
The colour temperature can be adjusted between 2700 K and 6500 K.
Lifetime (L75/B10): 100000 h. (tq+25°C)
Photobiological safety RG0.
SOURCE
Squared LED modules.
Colour initial tolerance (MacAdam): SDCM 3.
MECHANICAL
Housing in hot‑galvanised steel, painted in white polyester.
Honeycombed diagonal screen in white anti‑glare polycarbonate.
Height only 30 mm.
Installation in false ceilings with exposed structure.
ELECTRICAL
In compliance with EN 60598‑1.
Compliance with the EN 60598‑2‑22 standard for power supply from a centralised CPSS emergency system must be verified in the technical data sheets of each individual device on our website.
Cable with a DALI DT8 driver.
5‑pole terminal block (L‑N‑PE‑DA/DA) quick connection for line connection with connection capacity 2x2.5 mm² per poles.
INSTALLATION
Lay‑in installation.
APPLICATIONS
Any environments requiring light which aims for the wellness of people.
Environments where soft diffuse light is required for optimal visual comfort and total shielding of the source.
Representative environments, with video terminals, offices, meeting rooms, transit areas, reception and waiting rooms.
LIGHT MANAGEMENT
Tunable White products can be controlled with wired control systems or 3F & Casambi.
ON REQUEST
- different power levels or colour rendering indices
- emergency versions
Anti‑fall safety cable for fixing the housing to the building structure.
Length 2.5 m.
White painted polyester hot‑dip galvanised steel frame for 3F Dìagon Plafone.
Height only 40 mm.
