3F LEM HO Wide
Wide distribution with rectangular shape.
ON/OFF electronic wiring 230V‑50/60Hz
Code
Item
W
lm
K
CRI
L x A x H
IP
58953
3F LEM 1 HO LED 70 CR AMPIO
71
11303
4000
>80
542x115x150
65
58957
3F LEM 1+1 HO LED 140 CR AMPIO
138
22606
4000
>80
1099x115x150
65
58954
3F LEM 2 HO LED 140 CR AMPIO
138
22606
4000
>80
470x542x129
65
58955
3F LEM 3 HO LED 210 CR AMPIO
207
33909
4000
>80
657x542x129
65
58956
3F LEM 4 HO LED 280 CR AMPIO
276
45213
4000
>80
757x542x129
65
58958
3F LEM 5 HO LED 350 CR AMPIO
345
56516
4000
>80
952x542x129
65
DALI electronic wiring 230V‑50/60Hz
Code
Item
W
lm
K
CRI
L x A x H
IP
58971
3F LEM 1 HO LED 70 DALI CR AMPIO
71
11303
4000
>80
542x115x150
65
58975
3F LEM 1+1 HO LED 140 DALI CR AMPIO
138
22606
4000
>80
1099x115x150
65
58972
3F LEM 2 HO LED 140 DALI CR AMPIO
138
22606
4000
>80
470x542x129
65
58973
3F LEM 3 HO LED 210 DALI CR AMPIO
207
33909
4000
>80
657x542x129
65
58974
3F LEM 4 HO LED 280 DALI CR AMPIO
276
45213
4000
>80
757x542x129
65
58976
3F LEM 5 HO LED 350 DALI CR AMPIO
345
56516
4000
>80
952x542x129
65
3F LEM HO Medium
Medium distribution with square shape.
ON/OFF electronic wiring 230V‑50/60Hz
Code
Item
W
lm
K
CRI
L x A x H
IP
58968
3F LEM 1+1 HO LED 140 CR MEDIO
138
22128
4000
>80
1099x115x150
65
58965
3F LEM 2 HO LED 140 CR MEDIO
138
22128
4000
>80
470x542x129
65
58966
3F LEM 3 HO LED 210 CR MEDIO
207
33192
4000
>80
657x542x129
65
58967
3F LEM 4 HO LED 280 CR MEDIO
276
44256
4000
>80
757x542x129
65
58969
3F LEM 5 HO LED 350 CR MEDIO
345
55320
4000
>80
952x542x129
65
DALI electronic wiring 230V‑50/60Hz
Code
Item
W
lm
K
CRI
L x A x H
IP
58986
3F LEM 1+1 HO LED 140 DALI CR MEDIO
138
22128
4000
>80
1099x115x150
65
58983
3F LEM 2 HO LED 140 DALI CR MEDIO
138
22128
4000
>80
470x542x129
65
58984
3F LEM 3 HO LED 210 DALI CR MEDIO
207
33192
4000
>80
657x542x129
65
58985
3F LEM 4 HO LED 280 DALI CR MEDIO
276
44256
4000
>80
757x542x129
65
58987
3F LEM 5 HO LED 350 DALI CR MEDIO
345
55320
4000
>80
952x542x129
65
3F LEM HO Concentrated
Concentrated elliptical distribution.
ON/OFF electronic wiring 230V‑50/60Hz
Code
Item
W
lm
K
CRI
L x A x H
IP
58959
3F LEM 1 HO LED 70 CR CONC
71
10825
4000
>80
542x115x150
65
58960
3F LEM 2 HO LED 140 CR CONC
138
21649
4000
>80
470x542x129
65
58961
3F LEM 3 HO LED 210 CR CONC
207
32474
4000
>80
657x542x129
65
DALI electronic wiring 230V‑50/60Hz
Code
Item
W
lm
K
CRI
L x A x H
IP
58977
3F LEM 1 HO LED 70 DALI CR CONC
71
10825
4000
>80
542x115x150
65
58978
3F LEM 2 HO LED 140 DALI CR CONC
138
21649
4000
>80
470x542x129
65
58979
3F LEM 3 HO LED 210 DALI CR CONC
207
32474
4000
>80
657x542x129
65
3F LEM HO HRL
Concentrated distribution (Rack washer).
ON/OFF electronic wiring 230V‑50/60Hz
Code
Item
W
lm
K
CRI
L x A x H
IP
3F LEM 1 HO LED 70 CR HRL
71
11004
4000
>80
542x115x150
65
3F LEM 2 HO LED 140 CR HRL
138
22008
4000
>80
470x542x129
65
3F LEM 3 HO LED 210 CR HRL
207
33012
4000
>80
657x542x129
65
DALI electronic wiring 230V‑50/60Hz
Code
Item
W
lm
K
CRI
L x A x H
IP
3F LEM 1 HO LED 70 DALI CR HRL
71
11004
4000
>80
542x115x150
65
3F LEM 2 HO LED 140 DALI CR HRL
138
22008
4000
>80
470x542x129
65
3F LEM 3 HO LED 210 DALI CR HRL
207
33012
4000
>80
657x542x129
65
ILLUMINOTECHNICAL
Wide, medium, concentrated symmetric elliptical distribution.
Lifetime (L80/B10): 100000 h. (tq+25°C)
Photobiological safety RG0.
SOURCE
Linear LED modules.
Colour initial tolerance (MacAdam): SDCM 3.
MECHANICAL
Passive modular heatsinks in die‑casted aluminium, painted in white colour.
To optimize the thermal management of the LED module, the heatsinks are oversized and provided with self‑cleaning of cooling fins.
Wiring body in aluminium and galvanised steel anchored solidly to the sinks and thermally separated.
3F Lens lenses with high luminous efficiency, transparent methacrylate (PMMA), fixed to the LED modules.
Fixing brackets in stainless steel.
ELECTRICAL
In compliance with EN 60598‑1.
Compliance with the EN 60598‑2‑22 standard for power supply from a centralised CPSS emergency system must be verified in the technical data sheets of each individual device on our website.
Quick connection via 3/5 P connector.
Power unit positioned on a separate compartment by the LED module to ensure optimum temperatures of cabling components, to be inspectable and maintainable.
APPLICATIONS
Ambient temperature from ‑30°C to +55°C.
Dry, dusty indoor environments, subject to occasional water splashes.
Commercial, industrial and sporting environments (with no high‑flying balls), as well as warehouses.
Environments in which it is necessary a total protection against falling fragments (eg environments with foodstuffs or machines with moving parts or with extreme temperature changes), use luminaires with polycarbonate lenses.
LIGHT MANAGEMENT
The DALI products can be controlled with 3F Easy Dim or 3F Smart Dimming technology.
WARNING
Fixture not suitable for cold stores with an ambient temperature <0°C and/or relative humidity >85%.
ON REQUEST
- different power levels, colour rendering indices and colour temperatures
- double quick connection
- polycarbonate lenses (IK08)
- wiring: twin‑circuit, CLO
- linear LED modules, with special protection against aggressive chemically‑volatile substances, for standard LED technology
- HACCP versions
- versions with anti‑condensation filter
- emergency versions
Code
Item
A0652
Pair of brack. ceiling instal. 3F LEM
Brackets for mounting of luminaire on ceiling or on bus ducts, stainless steel.
Please note: these brackets do NOT provide free orientation of the luminaire. To allow free orientation, accessories A0651+A0632 must be installed.Brackets for ceiling mounting, in hot‑galvanised steel painted in white polyester.
The bracket A0632 allows the luminaire to be ceiling mounted without the possibility to rotate it.
To allow free orientation, both accessories (A0651+A0632) must be installed.Brackets for wall mounting, in in hot‑galvanised steel painted in white polyester.
The bracket A0654 allows the luminaire to be wall mounted without the possibility to rotate it.
To allow free orientation, both accessories (A0651+A0654) must be installed.Additional bracket that, combined with the A0654 or A0632 accessories, makes it possible for the luminaires to be oriented on the ceiling or the wall, in hot‑galvanised steel painted in white polyester.
This accessory must ALWAYS be used with one of the following codes: A0632 ‑ A0654.Brackets for rotating luminaries mounted on ceilings or on bus ducts.
Code
Item
A0728
Cover for food appl. 3F LEM 1
Dust covers for food processing areas in white‑painted galvanised steel.
For a LEM 3, for example, 3 pcs of the cod. A0733 must be ordered.
Not available for the 1+1 version.
Note: the maximum ambient operating temperatures of the fixtures decrease by 10°C in all families, except for the High Output versions in which the reduction is 5°C.
The reduction in the luminous flux emitted is equal to 3% in all models in the range.Code
Item
A0653
Pair of fixing carab.for chain instal.
Snap hooks clips for chain suspension, galvanised steel.
Glass with gasket to protect the louvre compartment from dust.
Recommended for use in very dirty environments.
Code
Item
A0242
15SS galvanized steel cable coil 100m
The pack contains 100 metres.A0243
15BF galvanized steel cable coil 500m
The pack contains 500 metres.Anti‑fall safety cable Ø 2 mm for fastening the body to the building structure.
Coupling accessory A0714 to one of the two safety cables (A0242 or A0243) provides an anti‑fall kit fixing and adjusting the cable on the load‑bearing element of the building structure.
The cable passes between the two passage holes on the hanging brackets.
Suitable for environments subject to impacts or seismic zones.Code
Item
A0714
Clamp 2 holes susp.- 100 pcs
The pack contains 100 pieces.Clamp in nickel‑plated brass suitable for fixing and adjustment of galvanised steel wire (diameter 1,25 mm 1,5 mm ‑ 2 mm), complete with locking screws.
The 2 hole clamp allows to block and adjust the cable on a bearing element (part of the building) or on rounded eye bolt.
Code
Item
A0521
Reducing sealing ring diam.8mm
Reducing sealing ring, dedicated to the use of cables with an external diameter of up to 8 mm.
